AKZO NOBEL
CASCO ADHESIVES
Phenol-Resorcinol Formaldehyde Resin
Suitable adhesive for fire door repairs
Fire door repair glue
There are various systems within the Casco range to meet varying application method and end user requirements. A typical system is as follows:
Cascosinol Phenol Rescorcinol Adhesive 1711 with Hardener 2520
The combination Cascosinol 1711 with hardener 2520 is approved by NTI, Norway, Otto-Graf insitut (FMPA), Germany, SKO/KOMO (DHBC N0. 32389), Holland for the Production of load-bearing timber structures.
The combination can also be used in door production, lamination, finger jointing and other applications in the wood working industry, where there is demand for high water and weather resistance for the joints. The combination has short pressing times even at lower pressing times.
Technical Data
Type
|
1711 Phenol Resorcinol glue
|
Delivery form
|
1711 liquid
2520 liquid
|
Colour
|
1711 dark brown
2520 greyish brown
|
Viscosity
|
Brookfield LVT, sp. 4, 12 r/min, 25°C
1711 approx. 5000 mPa.s
2520 approx. 8000 mPa.s
|
Density
|
1711 approx. 1150 kg/m³
2520 approx. 1220 kg/m³
|
Dry solids
|
1711 approx. 56%
|
pH
|
1711 approx. 8
2520 approx. 5
|
Flash Point
|
1711 70°C
2520 85°C
|
Other Data
Properties of the bond-line
|
Cascosinol 1711 with hardener 2520 fulfils the requirements according to EN 301 (for glue type I and II, service classes 1, 2, 3), EN 391, EN 392 and DIN 68141.
|
Storage life
|
1711 6 months at 20°C in well closed packaging
2520 6 months at 20°C in well closed packaging
If the packaging is left open when not in use the glue is susceptible to skin formation on the surface. To avoid this the packaging should be closed when not in use
|
Directions for use
Application tools
|
Roller spreader, ribbon spreader etc
|
Mixing ratio
|
1711 100 parts by weight
2520 15 parts by weight
The accuracy in the hardener amount shall be ± pbw.
|
Pot life
|
Temperature of glue mix 10°C 15°C 20°C 25°C 30°C
Pot life in hours 4½ 2¼ 1¼ 2/3 ½
When preparing large amounts of glue mixture, it is recommended to cool the glue to 10-15°C and after that add the hardener to extend the pot life.
|
Wood temperature
|
The temperature should not be lower than 20°C.
|
Moisture content of the wood
|
8 - 14 %. For the production of laminated beams 10 - 12%
|
Planing of the wood
|
Newly planed surfaces give the best gluing result. For best result at laminated mean production the timber must be smoothly planed. For optimum bonding strength the planing should take place within 24 hours before gluing.
|
Glue spread
|
For production of laminated beams a minimum glue spread of 400-450 g/m² single-sided is recommended. A reduction of the glue spread, e.g. at very short assembly times, is only allowed to be done together with the Casco Products Technical Advisors, depending on the production parameters for the production line in question. This optimization implies that the set parameters are followed and that a continuous control of the adhesion quality is made by means of delamination tests. At HF gluing a glue spread of 250-350 g/m² single-sided is recommended. At other applications: 150-300 g/m².
Difficult-to-glue wood or hardwood may require double spreading in amounts of 150-200 g/m² on each side.
|
Pressing temperature
|
Soft wood can be glued at a joint temperature of 20°C. To be sure to obtain a good result heating of the glue joint to 30°C is recommended. When gluing hard wood the temperature of the glue joint must be at least 40°C. Constructions with tensions and hard woods require at least 60°C to obtain adequate strength. Lowest pressing temperature has to be tried out. After the pressure is applied the heating can start.
|
Pressure
|
Minimum 0,5 MPa for soft wood
Minimum 1,0 MPa for hard wood
In laminated beam production:
Minimum 0,7 MPa for 33mm lamellas
Minimum 0,9 MPa for 45mm lamellas
According to DIN 1052/1-A1 the maximum allowed thickness of lamellae is 42mm.
|
Pressing time
|
The pressing time depends on the temperature, the distance to the innermost glue joint, the glue spread, etc. The table below may be used as a guideline.
|
|
Glue joint temperature
|
Minimum time for curing at indicated glue joint temperature
|
|
20°C
30°C
40°C
60°C
80°C
100°C
|
4 hours
2 hours
45 min
12 min
3 min
1 min
|
|
